Overall Dimensions of Plates
 Hight
 Width
 Thickness

 160mm
 230 mm
 4mm

 Dimmensions of Rectangular
 Notch Height
           Width

 82 mm
 30 mm

 Angle of vee notch weir

 90¢ªinclusive

 Hook & Point Gage Range

 0 to 150mm
 accuracy 0.1
